AMD is reportedly planning to introduce a brand new “3D core” to its CPU construction, in accordance with a brand new leak concerning the forthcoming AMD Zen 7 structure. What’s extra, we’re apparently not simply speaking a few large pool of additional cache right here, as seen on current chips such because the AMD Ryzen 7 9800X3D, however a layer of a number of cache slices sitting instantly under an infinite variety of CPU cores, in a construction that might turn out to be a regular a part of the structure.
On condition that we have but to see even AMD Zen 6 CPUs, not to mention Zen 7, it’ll be a very long time earlier than we see this tech being utilized in one of the best gaming CPU designs. The leak says Zen 7 is anticipated to launch both in late 2027 or early 2028, so it is at the very least two and a half years away, however I am actually intrigued about how this new AMD tech may work.
These rumored AMD Zen 7 particulars had been shared by YouTube tech leaker Moore’s Legislation is Useless (MLID), who might be hit or miss in relation to accuracy, so take them with a grain of salt, particularly as these are actually early days to be discussing Zen 7. Nonetheless, AMD has had some nice success with its X3D chips that reap the benefits of TSMC’s 3D silicon stacking tech, and it is smart for the corporate to make extra of it.
What is that this 3D Core, then? “I assumed that meant V-cache, proper? Simply X3D cores,” says MLID. “Effectively, really, the reply is not any. The reply right here is that there’s a new kind of purely 3D Core that makes use of a radical new 3D stacking design for tons of cache and a ton of efficiency with core depend will increase.”
In line with the leak, AMD Zen 7 core chiplets shall be manufactured utilizing TSMC’s 1.4nm tech, which might be really cutting-edge for the timeframe if that is true. Nonetheless, AMD is reportedly going to stay with TSMC’s 4nm course of for making its 3D V-cache. MLID additionally shared what he claims is part of a diagram exhibiting the construction of part of the Zen 7 structure, which you’ll be able to see under.
In it, you possibly can see one layer incorporates many components labeled “PT core” – with MLID claiming {that a} single Zen 7 chiplet may comprise 33 of those PT cores. That is an odd quantity in additional methods than one, which the YouTuber acknowledges, however sticks by it.
In the meantime, instantly below this layer of cores is one other layer containing a number of 7MB slices of L3 cache, probably one for every core. MLID discusses this tech in relation to AMD’s EPYC CPUs, however AMD normally makes use of the identical architectural designs throughout its complete product stack, and if this 3D Core is utilized in EPYC chips, there’s additionally a superb probability it can make it to Ryzen merchandise too.
The concept behind this leaked design, in accordance with MLID, is that 3D-stacking the L3 cache slices on this approach reduces latency, although it could additionally massively lower the house occupied by a chiplet and its cache on the package deal, whereas additionally probably ensuring that every core is ready to instantly entry an infinite quantity of cache.
Every core will reportedly even have 2MB of L2 cache on the die itself – double the quantity present in present Zen 5 CPUs. When you put this tech in a Ryzen gaming CPU, you would not want to fret about one core chiplet die not getting access to the 3D V-cache, as in present Ryzen 9 X3D chips – each core may probably have its personal stack of L3 cache as commonplace, or there could also be methods for the chip to see the whole thing as one big pool as effectively.
In line with MLID, AMD is trying to enhance the directions per clock (IPC) of its CPU cores by 15-25% with the transfer to Zen 7, whereas specializing in cutting-edge tech, with the purpose of not being left behind by Intel once more. In fact, we can’t understand how precisely this tech will work, or if it even exists, till AMD decides to elevate the lid on Zen 7 itself, and that is a good distance sooner or later. It is thrilling to take a look at what may be on the playing cards, although.
When you’re pondering of shopping for a brand new CPU proper now, try my Ryzen 7 9800X3D evaluate to see why AMD’s 3D V-cache is so good for gaming efficiency, and you too can learn my tutorial on learn how to set up a CPU to ensure your improve goes easily.
